E-motor | 1000W36V neodymium magnet DC motor |
OPTIONAL E-motor A | 1100W36V |
Battery | 3X12V9AH lead acid |
OPTIONAL BATTERY A | 36V13Ah lithium |
OPTIONAL BATTERY B | 36V10Ah lithium |
Max. output power(kw/r/mim) for 36V1000W | 1.80 / 1600 |
Max. output power(kw/r/mim) for 36V1100W | 1.90 / 1500 |
Max. torque(N.m) for 36V1000W | 10.40 |
Max. torque(N.m) for 36V1100W | 11.90 |
Transmission | intelligentized controller,3 function adjustable (see info. below) throttle response speed adjustable from 0.2S to 1.0S motor power output adjustable from 10A to 35A |
max speed | 28kmph |
Max load capacity | 65kgs |
Load quantity | 84pcs/20FT ; 200pcs/40HQ |
Brake system | front and rear mechanical disc ( Ø180mm) brake |
Suspension | hydraulic inverted fork and rear mono shock |
Dimension | 1330*640*865 mm |
Wheelbase | 920mm |
Seat height | 620mm |
Min ground clerance | 250mm |
Dry weight | 42kgs- lead acid battery / 36kgs- lithium battery |
Package carton size | 1170*355*640mm |
